| Quantity: | |
|---|---|
Superior Sealing Performance
Soft seats (EPDM, NBR, PTFE) ensure zero leakage even under fluctuating pressures and temperatures58.
Resilient materials adapt to minor pipeline misalignments, reducing wear3.
Corrosion and Chemical Resistance
PTFE-lined seats withstand aggressive media like acids, alkalis, and solvents, ideal for chemical and pharmaceutical industries86.
Automation Compatibility
Pneumatic actuators (ISO 5211-compliant) enable quick 90° operation, with fail-safe options for critical systems712.
Lightweight and Compact Design
30–50% lighter than gate valves, reducing installation costs and structural load1012.
Low Maintenance
Minimal moving parts and easy seat replacement extend service life38.
Water & Wastewater Treatment: Chlorine and ozone resistance in disinfection systems58.
Chemical Processing: Handling corrosive fluids like acids and solvents68.
Food & Beverage: FDA-compliant materials for hygienic processes511.
HVAC: Regulating steam and chilled water in commercial systems12.
Pharmaceuticals: High-purity fluid control with PTFE seats8.
| Parameter | Details |
|---|---|
| Size Range | DN40 (1.5") to DN1200 (48") |
| Pressure Rating | PN10/16, ANSI 150/300 |
| Temperature Range | -20°C to 200°C (-4°F to 392°F) |
| Materials | Body: Ductile iron, SS304/316; Disc: SS304/316; Seat: EPDM, NBR, PTFE |
| Actuator Standards | ISO 5211, ATEX (for explosive environments) |
| Certifications | ISO 9001, API 609, FDA |
Regular Inspection
Check seat integrity and disc alignment every 6–12 months to prevent leaks38.
Lubrication
Apply food-grade grease to the stem annually for smooth operation7.
Seat Replacement
Replace PTFE/EPDM seats every 5–7 years in high-wear applications8.
Avoid Over-Tightening
Use torque wrenches during installation to prevent seat deformation3.
Certified Safety: Complies with ATEX, FDA, and ISO standards for hazardous environments812.
Cost Efficiency: Reduced downtime and maintenance costs compared to metal-seated valves10.
Customization: Options include fire-safe designs, gear operators, and exotic materials (e.g., Viton®)611.
Title Tags: Use keywords like "Pneumatic Soft Seat Butterfly Valve | Zero-Leakage & FDA-Compliant".
Meta Descriptions: Highlight benefits (e.g., "Durable, corrosion-resistant pneumatic valves for chemical and food industries—ISO-certified").
Header Tags: Structure with H2/H3 headers like "Applications in Pharmaceutical Industries" or "Maintenance Best Practices".
Image Alt Text: Include descriptive phrases (e.g., "PTFE-lined pneumatic butterfly valve diagram").
Backlinks: Partner with industrial directories or blogs (e.g., chemical engineering forums)10
